rounded, r = 113 mm, with drip edge, with window frame connection, 30 mm high, depth 62 mm
Request articleRequest this article online at Olfry.
Find selected reference buildings in your area:Find selected reference buildings in your area:
ConfiguratorConfigure your dream home online and let yourself be inspected.
Contact partnerWe are happy to advise you personally. Here you will find your OLFRY customer advisor.
Formats, dimensions and weights
Masonry without efflorescence protection
Rainwater penetrates through the masonry and washes out the efflorescent components of the mortar.
Sulphates and carbonates migrate to the outside when the unprotected masonry dries out and crystallize on the surface.
The result is that there are unwanted white spots (efflorescence) on the facing brick.
OLFRY masonry with efflorescence protection
The efflorescence protection, with its molecularly fine, water-repellent layer (approx. 2–4 mm), acts like a protective shield: rainwater can only enter through the joints.
The pores and capillaries of the brick remain open even with efflorescence protection, so the block remains breathable. The moisture in the joints can penetrate unhindered into the brick via the bearing surface – the brick retains its important function as a moisture buffer.
When the masonry dries, the stored moisture migrates as water vapour through the capillary system to the outside again. However, since water vapour does not transport soluble sulphates and carbonates, these do not penetrate to the surface, as is the case with unprotected bricks. And the successful result is naturally beautiful bricks without unsightly efflorescence.
Our new 3D configurator gives you a realistic impression of your dream façade. Let yourself be inspired.
